PM COLOSSUS 84K / 100K / 120K

PM COLOSSUS 84K / 100K / 120K

Floodlight with a large dissipation area with a structure made of sheet steel and internal bodies in die-cast aluminium. Symmetrical or asymmetrical internal louvres specially designed to cover large surfaces, improve directional light flow and avoid glare. 4mm tempered glass enclosure. Internal wiring fireproof. PCB with 3535 L90B10 LED with efficiency greater than 170 Lm/W, CRI>80 and estimated life > 100,000h. Adjustable strip support for greater projection.

Models

REF W LM LM/W
PM-COLOSSUS 84K 475 W 511 W 83.814 lm 78.048 lm 176 153
PM-COLOSSUS 100K 565 W 608 W 100.629 lm 93.705 lm 178 154
PM-COLOSSUS 120K 675 W 726 W 120.175 lm 111.907 lm 178 154

Nominal data

Real data

Configurable Options

CRI COLOUR
74 2700K
74 4000K
73 5700K
AMBAR

Equivalences

PM-COLOSSUS 84K PM-COLOSSUS 100K PM-COLOSSUS 120K
Efficieny 246 W 320 W 400 W
Traditional LED 365 W 475 W 595 W
Metal halide 695 W 905 W 1.135 W
Discharge lamp 900 W 1.180 W 1.475 W

Lens

LENS TYPE
10º SYMMETRICAL
30º SYMMETRICAL
60º SYMMETRICAL
90º SYMMETRICAL

Data sheets



PM-COLOSSUS Data sheets

Extra Options

REGULATION TREATMENTS OTHERS
DALI 1-10 R.M.SYSTEM ANTISALINE ANTICORROSION CRI 80 TLCI > 90
84K-120K

Included

Available

Consult
